CABLES

STANDARD CABLES and CABLES BUILT TO YOUR SPECS.

McNEILUS cables

THROTTLE CABLES

0215833  45826-396 McNeilus Throttle Cable 44BP396

$79.80

10-32 Thread, 3"Stroke, Bulkhead-Clamp
PART NUMBER-LENGTH MTM REX
3323-180" . 102-07245-80
3323-220" . 102-07245-01
3323-240" . 102-07245-02
3323-252" . 102-07245-03
3323-274" . 102-07245-04
3323-292" . 102-07245-05
3323-310" . 102-07245-06
3323-328" . 102-07245-07
3323-340" . 102-07245-09
3323-360" . 102-07245-10
1/4-28 Thread, 3"Stroke, Bulkhead-Plain End
PART NUMBER-LENGTH MTM REX
45508-360" 380.00830....... .
1/4-28 Thread, 4"Stroke, Bulkhead-Plain End
PART NUMBER-LENGTH MTM REX
45826-360" 380.215830..... .
45826-396" 380.215833... .

CONTROL CABLES

1/4"-28 Thread, 3"Stroke, Bulkhead-Bulkhead
PART NUMBER-LENGTH MTM REX SMITH
4322-48" . 102-07554-12 520-4137004
4322-60" 380.00805 102-07554-08 520-4137005
4322-72" 380.00806 102-07554-09 520-4137001
4322-84" 380.00807 102-07554-10 520-4137002
4322-96" 380.00808 102-07554-13 520-4137003
4322-108" 380.00809 . 520-4137006
4322-120" 380.00810 102-07554-11 520-4137007
4322-132" 380.00811 102-07554-03 520-4137008
4322-144" 380.00812 102-07554-04 520-4137009
4322-156" 380.00813 102-07554-07 520-4137010
4322-168" 380.00814 102-07554-06 520-4137011
4322-180" 380.00815 102-07554-02 520-4137012
4322-192" 380.00816 102-07554-05 520-4137013
4322-204" 380.00817 . 520-4137014
4322-216" 380.00818 . 520-4137015
4322-228" 380.00819 . 520-4137016
4322-240" 380.00820 . 520-4137017
4322-252" 380.00821 . 520-4137018
4322-264" 380.00822 . 520-4137019
4322-276" 380.00823 102-07554-01 .
4322-288" 380.00824 . 520-4137020
4322-300" 380.00825 . 520-4137021
4322-312" 380.00826 . .
4322-324" 380.00827 . 520-4137022
4322-336" 380.00828 . .
4322-348" 380.00829 . .
4322-360" . . .
1/4"-28 Thread, 4"Stroke, Bulkhead-Bulkhead
PART NUMBER-LENGTH MTM REX SMITH
4422-48" . . .
4422-60" 380.215805 . .
4422-72" 380.215806 . .
4422-84" 380.215807 . .
4422-96" 380.215808 . .
4422-108" 380.215809 . .
4422-120" 380.215810 . .
4422-132" 380.215811 . .
4422-144" 380.215812 . .
4422-156" 380.215813 . .
4422-168" 380.215814 . .
4422-180" 380.215815 . .
4422-192" 380.215816 . .
4422-204" 380.215817 . .
4422-216" 380.215818 . .
4422-228" 380.215819 . .
4422-240" 380.215820 . .
4422-252" 380.215821 . .
4422-264" 380.215822 . .
4422-276" 380.215823 . .
4422-288" 380.215824 . .
4422-300" 380.215825 . .
4422-312" 380.215826 . .
4422-324" 380.215827 . .
4422-336" 380.215828 . .
4422-348" 380.215829 . .
4422-360" . . .
5/16"-24 Thread, 3"Stroke, Bulkhead-Bulkhead
PART NUMBER-LENGTH MTM REX SMITH
6322-60" 380.00835 102-07244-17 520-2131005
6322-72" 380.00836 102-07244-18 520-2131001
6322-84" 380.00837 102-07244-11 520-2131002
6322-96" 380.00838 102-07244-19 520-2131003
6322-108" 380.00839 102-07244-20 520-2131006
6322-120" 380.00840 . 520-2131007
6322-132" 380.00841 . 520-2131008
6322-144" 380.00842 102-07244-12 520-2131009
6322-156" 380.00843 102-07244-13 520-2131010
6322-168" 380.00844 102-07244-14 520-2131011
6322-180" 380.00845 102-07244-01 520-2131012
6322-192" 380.00846 102-07244-02 520-2131013
6322-204" 380.00847 102-07244-03 520-213014
6322-216" 380.00848 102-07244-04 520-2131015
6322-228" 380.00849 102-07244-05 520-4137016
6322-240" 380.00850 102-07244-06 520-2131017
6322-252" 380.00851 102-07244-07 520-2131018
6322-264" 380.00852 102-07244-08 520-2131019
6322-276" 380.00853 102-07244-09 520-8488
6322-288" 380.00854 102-07244-10 520-2131020
6322-300" 380.00855 102-07244-22 520-2131021
6322-312" 380.00856 102-07244-25 .
6322-324" 380.00857 102-07244-21 520-2131022
6322-336" 380.00858 102-07244-23 .
6322-348" 380.00859 . .
6322-360" . 102-07244-24 520-2131023
5/16"-24 Thread, 4"Stroke, Bulkhead-Bulkhead
PART NUMBER-LENGTH MTM REX SMITH
6422-132" . . 520-5010988
6422-144" . .
6422-156" 380.16213 . .
6422-168" . . .
6422-180" 380.16569 . .
6422-192" 380.16563 107-00172-06 .
6422-204" 380.16555 107-00172-07 520-5010939
6422-216" 380.16556 107-00172-08 .
6422-228" 380.16557 107-00172-09 520-5010941
6422-240" 380.16558 107-00172-10 .
6422-252" 380.16559 107-00172-11 520-5010943
6422-264" 380.16560 107-00172-12 520-5010944
6422-276" 380.16587 107-00172-13 .
6422-288" 380.16561 107-00172-14 520-5010945
6422-300" 380.16562 107-00172-15 520-5010946
6422-312" 380.16568 107-00172-16 520-5010953
6422-324" 380.16567 107-00172-17 .
6422-336" 380.16564 . .
6422-348" 380.16565 . 520-5010950
6422-360" 380-16566 . 520-5010951
